Lower half of upper bell for heat exchange. Note the cleanout access opening on the left side.
Next
Prev
The top, with the chimney/stovepipe hole which still needs some work (right-most bricks not mortared in).
Upper half of upper bell. The firebrick spanning the U-shape blocks heat from a direct path to the chimney, which will exit through the little 6.5x6.5
Left side with cleanout port.
Lower half of upper bell for heat exchange. Note the cleanout access opening on the left side.
Outer core up. Now to build the firebox inside it.
2nd course.
Cast refractory tile for spanning/capping the firebox.
